WISENSOR 100 Real-Time IoT Cargo Tracker Sensor
Industrial multi-sensor logistics tracker built for global supply chain environmental monitoring. Integrated temperature, humidity, shock, tilt, light and multi-mode positioning module, providing full-lifecycle cargo data recording and real-time cloud alert.
4G LTE-M + NB-IoT Global
3 Years Ultra Long Standby
IP67 Industrial Housing
Cold Chain FDA Certified
Product Details
Product Description
Detection Principle | Capacitive Measurement |
Temperature Measurement Range | Temperature Measurement Range: -30°C to 80°C |
Humidity Measurement Range | 0 ~ 100% RH |
Temperature Measurement Accuracy | ±0.5℃(typical 0-60°C, minimum or maximum temperature accuracy not exceeding ±1.5°C) |
Humidity Measurement Accuracy | ±5% RH(typical 20-80% RH, minimum or maximum humidity accuracy not exceeding ±7% RH) |
Communication Frequency Band | 433/470/868/915 MHz |
Protocol | Proprietary protocol, LoRaWAN protocol |
Indoor Communication Distance: | 100 meters |
Visible Communication Distance: | 400 meters |
Gateway Support | Designated gateway model, one gateway supports 35-40 sensors |
Operating Voltag: | 3.6V |
Operating Current | ≤130mA, duration within 1 second |
Sleep Current | ≤10uA |
Battery Capacity | 4000mAh,replaceable |
Feature Overview
产品图片占位
WI-SHT10 Temperature and Humidity Sensor
The WI-SHT10 series temperature and humidity sensor is a digital sensor based on wireless technology, powered by a high-capacity lithium-thionyl chloride battery, and designed specifically for monitoring applications in harsh environments. Its design overcomes the limitations of wiring and power supply in many locations, meeting customers' plug-and-play needs. The sensor has a temperature measurement range of -30°C to 80°C and a humidity measurement range of 0 to 100% RH, with a typical accuracy of ±5% RH and ±0.5°C. The WI-SHT10 series sensor offers industrial-grade quality and reliability, consistent accuracy over a wide measurement range, and excellent cost-performance.
It is mainly used in cold chain transportation, pharmaceutical storage, indoor temperature and humidity monitoring, data centers, smart buildings, warehouses, agricultural greenhouses, various laboratories, museums, and more.
It is mainly used in cold chain transportation, pharmaceutical storage, indoor temperature and humidity monitoring, data centers, smart buildings, warehouses, agricultural greenhouses, various laboratories, museums, and more.
Toplogy
拓扑图占位
Features
√ Utilizes high-precision sensor chips and industrial-grade high-performance wireless modules;
√ Features an LCD display for intuitive temperature and humidity data, allowing users to monitor in real-time;
√ Supports customizable transmission intervals, with an elegant integrated design made of ABS flame-retardant material;
√ User-friendly and easy to use, with instant data transmission upon startup;
√ Equipped with a high-capacity lithium-ion battery, ultra-low power consumption, long standby time, and simple wall-mounted installation;
√ IP65 waterproof rating, suitable for direct use in harsh environments without external wiring;
√ Open protocol, compatible with TCP, Modbus, MQTT, and other protocols.
Application
应用场景图占位
Monitorable:
√ Medicine refrigerators
√ Freezers
√ Ultra-low temperature freezers
√ Liquid nitrogen devices
√ Ovens
√ Cold storage
√ Laboratories
√ Warehousing
√ Liquid nitrogen devices
√ Ovens
√ Cold storage
√ Laboratories
√ Warehousing
Size chart
尺寸图占位
Case
产品外壳图占位
